Outdoor Rental Mesh Led Display Screen Gflow With A Transparency Rate Of Over 60% P10.4 500500mm/5001000mm

Brand Name : gcl

Model Number : Gmesh

Certification : EMC/CE/ROHS/CCC/FCC/BIS

Place of Origin : Shenzhen, China

MOQ : Min. order: 20

Price : Negotiable

Supply Ability : 5000 Square Meter/Square Meters per Month

Delivery Time : 15-20Days

Packaging Details : Packing with Flight case & Wooden box & Hard paper box

Application : outdoor

Color : full color

Panel Size : 500*500mm\500*1000mm

Warranty : 3 Years

Pixel Pitch : P3.91\P10.4

Port : Shenzhen

brightness : 5000nits

color depth : 256

Cabinet weight : 6Kg

Transparency : 60%

Contact Now

Outdoor Rental mesh Led Display Screen Gflow With A Transparency Rate Of Over 60% P3.91-10.4 500*500mm/500*1000mm

Products Description

◇ Concave and Convex Curve Lock

The -15° to +15° curve locks allow compatibility with straight, concave, and convex configurations, making them suitable for various application scenarios

◇ Outer 90-Degree Angle Installation

Supports outer 90-degree angle installation, allowing for a variety of creative displays in rental applications

◇ Lightweight Design

The cabinet features a die-cast aluminum design, weighing only 18kg per square meter, ensuring no pressure on building structures. With a thickness of just 75mm, it allows for easy installation and maintenance by a single person

◇ Two Cabinet Sizes

The 500×500mm and 500×1000mm cabinet sizes can be freely combined and used together vertically, saving operational costs and installation time

◇ Multiple Cabinets Configured for 1000x1000mm Shipment

Before shipment, multiple cabinets can be configured to a size of 1000×1000mm, significantly reducing on-site installation time and improving work efficiency

◇ High Brightness & High Contrast

The brightness of 4500 nits ensures exceptional performance during daytime rental events. With a contrast ratio of 6000:1, it guarantees outstanding display quality even during evening rental activities

Name	Gflow P3.9	Gflow P10.4
Pixel Pitch(mm)	3.9-7.8	10.4-10.4
Densiy (pixels/㎡)	32768	9216
LED Type	SMD1921	SMD2727
Brightress (nits/㎡)	≥5000cd/㎡	≥5000cd/㎡
Scan Method	1/8S	1/2S
Cabinet Size(mm)	500100075mm/50050075mm	500100075mm/50050075mm
Module Size(mm)	50012512mm	50012512mm
Cabinet Material	Die-casting Aluminum	Die-casting Aluminum
CabinetWeight	500500 6kg 5001000 9kg	500500 5.5kg 5001000 8.5kg
Protection Level	IP65	IP65
Cabinet Maintenance	Rear Service	Rear Service
Max Power Consumption/㎡	700 W	700 W
Average Power Consumption/㎡	150W	150W
Refresh Rate	3840HZ	3840HZ
Transparency	50%	50%
Viewing Angle	H140°, V140°
Certifications	EMC/CE/ROHS/CCC/FCC/BIS
